Techical Parameter:
<
| TYPES OF MACHINE | SH120 | ||
| Injection Station Part | Unit | A | B |
| Screw diameter | mm | 45 | 50 |
| Injection pressure | Mpa | 174 | 141 |
| Screw L/D ratio | ---- | 21:1 | 19:1 |
| Screw stroke | mm | 172 | |
| plasticizing capacity | cm3/S | 32 | |
| injection rate | g/S | 106 | |
| injection volume | cm3 | 274 | 338 |
| Theoretic Injection weight(PS) | g | 258 | 319 |
| OZ | 9.1 | 11.2 | |
| Injection Station Impetus | KN | 54 | |
| Screw speed | r.p.m | 180 | |
| Shot stroke | mm | 260 | |
| Clamping Unit | Unit | ||
| Clamping force | KN | 1200 | |
| Clamping stroke | mm | 350 | |
| Mould Thickness | mm | 175-450 | |
| Space between tie bars | mm | 410×360 | |
| Ejector force | KN | 34 | |
| Ejector stroke | mm | 80 | |
| Ejecter Pin Number | ---- | 1 | |
| Others | Unit | ||
| Hydraulic system power | Mpa | 14 | |
| Temp. control zones | ---- | 3+1 | |
| Pump Servo motor power | KW | 11 | |
| Heating power | KW | 10 | |
| Overall Electric Power | KW | 22 | |
| Net Weight | t | 4 | |
| Sizes(L×W×H) | m | 4.25×0.95×1.8 | |
| Oil Box Capacity | L | 240 | |
